Asrock H370M-HDV - Alpha Components

4 x USB3.2 Gen1 Delivering data transfer rates up to 10X faster than USB 2.0 with optimized power efficiency. USB 3.2 Gen1 technology advances the data transfer rate up to 5Gb/s. ASRock provides 4 x USB 3.2 Gen1 ports onboard allows you to have a stunning data transfer experience.

3 Graphics Outputs Complete with all three types of most used connectors! Packed with a D-Sub + DVI-D + HDMI combo. Plus the HDMI ports supports 4K resolution.

HEVC 10-bit Decoding/Encoding Supports HEVC 10-bit Decoding/Encoding to provide substantially improved video quality and higher bit depth video experience.

Water Pump Header This is not only a standard CPU fan header, but also supports water pumps! This header provides a maximum of 2A power for supporting the most popular water pumps. User also can adjust the voltage of water pump to get higher cooling performance with lower noise.

Triple Monitor Graphics, graphics and even more graphics! You've demanded for more eye candy, so this motherboard supports Triple Monitor. You may choose up to three display interfaces from the rear i/o to connect monitors and use them simultaneously without installing another graphics card.

Product Description	Asrock H370M-HDV, Intel H370, 1151, Micro ATX, 2 DDR4, VGA, DVI, HDMI
Motherboard Type	Desktop
Form Factor	MicroATX
Socket	Intel 1151 - Coffee Lake
Chipset	Intel H370
CPU Support	See Intel website
RAM Technology	DDR4 (Dual Channel)
RAM Slots	2 x Dimm
RAM Speed	2666 / 2400 / 2133 MHz
Max RAM	64GB
Graphics	Supports Intel HD Graphics
Graphics Ports	1 x VGA1 x DVI-D1 x HDMI
Multi GPU Support	-
PCI/PCI Express	1 x PCIe 3.0 x161 x PCIe 3.0 x1
Storage	4 x SATA III1 x M.2 (2242/2260/2280) - SATA & PCIe
RAID	RAID 0, 1, 5, 10
Wireless	-
LAN	GB LAN
Audio	7.1 CH HD Audio (Realtek 887/897 Audio Codec)
USB ports Supported	4 x USB 3.2 Gen1 (2 at back, 2 at mid-board) 6 x USB 2.0 (4 at back, 2 at mid-board)
Back I/O Panel	1 x PS/2 Mouse/Keyboard 1 x D-Sub 1 x DVI-D 1 x HDMI 4 x USB 2.0 2 x USB 3.2 Gen1
Internal I/O Panel	1 x TPM 1 x Chassis Intrusion and Speaker 1 x CPU Fan 1 x Chassis/Water Pump Fan 1 x 24 pin ATX 1 x 8 pin 12V 1 x Front Audio 1 x USB 2.0 1 x USB 3.2 Gen1
Accessories	Quick Installation Guide, Support CD, I/O Shield2 x SATA Data Cables
Windows 11 Ready	Yes
Other Information	-
Package Type	Retail
Weight & Dimensions	-
Package Weight	0.69
Warranty	2 Year Replacement Warranty
